Geberit 111.625.00.1 Duofix element for urinal, 112?130 cm, universal
Duofix carrier installation frame for wall-hung urinal Universal.
For installation of concealed flush valves for wall-hung urinal
For installation in wood or steel stud walls that provide support in a minimum 3" (75 mm) depth
For single flush
For room wall or preWall construction covered with panels (gypsum or wood)
For installation in front of a solid or drywall
For installation in room-height preWall or partition wall
For a floor construction of 0 - 8 in (0 - 20 cm)
For 2-hole stud mounted wall-hung urinal with rear water inlet
With adjustable fixture, supply, drain and valve mounitng elevations and/or widths
Supports up to 110 lbs (50 kg)
Not suitable for hanger-type urinals with flushometer spud connections
Water supply connection at right
Self-locking feet for tool-free alignment of the element
Feet galvanized, infinitely adjustable 0 - 8 in (0 - 20 cm)
Flow rate at 15 psi (1 bar): 3.8 / 4.7 gpm without flow limiter (0.24 / 0.3 l/s)
Water test pressure: 230 psi (16 bar)
Operating pressure range: 14 - 116 psi (1 - 8 bar)
Frame, rough-in box, water supply, drainage elbow
2 threaded rods M8 for ceramics fastening
Vaccuum breaker
Fastening material
