Frost-Proof Automatic Draining Wall Hydrants with Backflow Preventer
Size(s):
1/2x1/2, 3/4x1/2, 3/4x3/4 in. (15x15, 20x15, 20x20mm)
Series FHB Frost-Proof Automatic Draining Wall Hydrants with Backflow Preventer are used in commercial and residential applications to provide freeze protection and backflow protection of the external water supply. It consists of a brass body construction with nickel-plated finish and 3/4 in. (20mm) hose outlet, replaceable bibb washer (without removing sill cock from water line), vacuum breaker, backflow preventer, and a steel handwheel. Series FHB has a positive seat water shutoff and an automatic self-draining feature. Available with 1/2 in. (15mm) copper or 1/2 in. (15mm) male IPS inlet (Model FHB-1), 1/2 in. (15mm) PEX inlet (FHB-1-PEX), 3/4 in. (20mm) male IPS or 1/2 in. (15mm) female IPS inlet (Model FHB-2), or 3/4 in. (20mm) copper inlet or 3/4 in. (20mm) male IPS (Model FHB-2 3/4).
